Black Pearl by Flysight - 32CH Diversity 7" FPV Monitor

This product is currently sold out.

Quick Details

  • Style: Radio Control Toy
  • Type: Helicopter
  • Power: Battery
  • Material: Plastic
  • Plastic Type: ABS
  • Scale: 1:5
  • Radio Control Style: RC Model
  • Brand Name: flysight
  • Model Number: RC801
  • Screen: 7 inch
  • Bracket: Folding
  • Battery: Li-battery 4600mAH
  • Channel Number: 32channel RC801
  • Antenna Connections: SMA and RPSMA optional

Specifications

RC801 Flysight Black pearl diversity monitor
5.8GHz Diversity
7 inch HDMI fpv monitor for dji phantom

RC801 Flysight Black Pearl  best seller no bluescreen 7 " fpv 5.8GHz Diversity 32ch  fpv monitor for dji phantom Promotion















Product Description

1.Features

  • 7" HDMI 1024*600 Screen
  • Two screen options: Matte screen and Mirror/brilliant screen
  • 5 modes support: Diversity/RX1/RX2/AV IN//HDMI mode
  • No "blue screen" .
  • Support Image Zoom Function;
  • Support Fatshark Nextwave&Airwave TX without distorted picture;Support image rotation 180 degree;
  • Built_in Dual Receiver Automatically for best reception Automatic Antenna Switching
  • Dual buffered AV outputs
  • Can receive 2 different channels at the same time
  • Not affect by 2.4GHz R/C Radios
  • Anti-black, anti-blue, anti-flash.
  • AV Receiver with Diversity inputs,AV, HDMI
  • Small, light weight, durable,stylish
  • 32 Channels



2.Specifications



Display Screen

Diagonal:    7 inch

Resolution: 1024X600

Contrast:    700:1

Luminance: 400cd/m^2



Wireless Receiving

Working frequency:

(5740MHz,5760MHz,5780MHz,5800MHz,

5820MHz,5840MHz,5860Mhz,)

Sensitivity:      -90dBm±1dBm

Channel:          7Channel ( Fband Channel )

Antenna Port:   2 X SMA,50ohm

Diversity receiving: Antenna diversity

TV System: NTSC/PAL

Video output level: 1.0Vp-p Typ,75ohm

Audio output level:1.0Vp-p Typ,10Kohm



AV Port

RX1 AV OUT:      Video,Audio output

RX2 AV OUT:      Video,Audio output

DIV AV OUT:      Diversity receiving, Video,Audio output

AV IN:            Video,Stereo Audio input HDMI IN(A Type) Support

HDMI:            1.3 Digital Input, Support HDMI Audio in

Built-in Microphone:  8Ω/1W X 2



Power Supply

DC IN:  7~28V/ 2A

DC OUT: Output Voltage:DC IN or battery voltage

                Output Current: 1A

Battery:  11.1V/1000mAh(3 series LiPo cells)

Consumption: 12V input:7.8W Dimensions



Dimensions

Main Body:  183X126X19.5mm(not include sun shadow)

Battery:  105X87.5X6.7 mm(not include prominent part)



Weight

Main body:  350 g

Battery:   95 g



Tripod connector: General 1/4 "thread



Working Temperature: -10°C~+65°C





Remark

  • High sensitivity diversity receivers for the best possible reception
  • Supports DNR
  • High resolution screen (1024x600px)
  • No blue screen
  • Supports Airwave and NextWave transmitters and many others on 5.7Ghz due to the 32Channel diversity receiver.
  • Supports image rotation.
  • HDMI 1.3 digital input port



3. Flysight Frequency:









Product Image

RC801 Black Pearl















RC801 Black pearl kits including:



Packing Details
1*Main Body
1*Sun Shadow
2*SMA Antennas
2*AV Cable
1*DC Input Cable
1*DC output Cable
1*Battery
1*Charger



 RC801 Flysight Black Pearl 7" FPV LCD Monitor



Display Screen

Diagonal

7 inch

Resolution

1024X600

Contrast

700:1

Luminance

400cd/m²























Wireless Receiving





Working frequency

ISM 5.8GHz

Band

CH 1

CH2

CH3

CH4

CH5

CH6

CH7

CH8

A

5865M

5845M

5825M

5805M

5785M

5765M

5745M

5725M

B

5733M

5752M

5771M

5790M

5809M

5828M

5847M

5866M

E

5705M

5685M

5665M

5645M

5885M

5905M

5925M

5945M

F

5740M

5760M

5780M

5800M

5820M

5840M

5860M

5880M

Sensitivity

 -90dBm±1dBm

Channel

 32Channel ( 4 Band X 8 Channel )

Antenna Port

 2 X SMA,50ohm

Diversity receiving

 Antenna diversity

TV System

 NTSC/PAL

Video output level

 1.0Vp-p Typ,75ohm

Audio output level

 1.0Vp-p Typ,10Kohm









AV Port





RX1 AV OUT

 Video,Audio output

RX2 AV OUT

 Video,Audio output

DIV AV OUT

 Diversity receiving, Video,Audio output

AV IN

 Video,Stereo Audio input

HDMI IN(A Type)

 Support HDMI 1.3 Digital Input, Support HDMI Audio in

Built-in Microphone

8Ω/1W X 2





Power Supply

DC IN

 7~28V/ 2A

DC OUT

 Output Voltage:DC IN or battery voltage

Output Current:1A

Battery

11.1V/1000mAh(3 series LiPo cells)

Consumption

12V input:7.8W
